Calidrawer VW T7 Beach Camper

Rear pull-out drawer for the T7 California Beach Camper

Standard with one-hand operation.

Features a robust, durable aluminium drawer with a natural aluminium finish.

Features a proven raised edge above the sturdy rail. The aluminium drawer has cutouts at the front and rear for securing cargo with tie-down straps or elastic cords.

Base made of CNC laser-cut aluminium angle profiles with a brushed finish (supplied with protective film).

The aluminium drawer is made of 3 mm thick material with a natural aluminium finish.

Simple and quick attachment to the T7 rail system. Attachment to special awning rails in the seat rails.

Very robust, heavy-duty rails lock automatically in both the open and closed positions.

The aluminium drawer has a 60 mm raised edge on three sides and a 30 mm raised edge at the operating point. A black fleece mat is placed in the drawer. It has a pleasant, soft surface that is easy to vacuum.

The back is fitted with rubber granules for extra slip resistance.

The total dimensions of the drawer are approximately 57 cm wide and 103 cm deep.

The internal dimensions of the drawer tray are 513 x 1001 mm.

Weight: approximately 15 kg

A 6 mm thick plate is located above the rail. This is followed by a clearance of 12 mm for the drawer and the drawer itself, which is 3 mm thick. This results in a total space loss of no more than 21 mm – no more than the bottom of a standard box.

The rear drawer is very sturdy and, thanks to the even weight distribution in the aluminum drawer tray, can bear a load of 150 kg.

The original! Proven thousands of times!
